Rising stem forged steel gate valve

  • Size: :1/2" to 2"
  • Temperature: :-29°C to 425°C
  • Pressure Rating: :up to 138 bar
  • Application medium: :Throttle steam, gas or liquids
  • Material: :Forged Steel A105N body and bonnet
  • Design Standard: :API602, BS5352, ASME B16.34

We're here to help:
Easy ways to get the answers you need.

  • Product description
  • Inquiry
Rising stem forged steel gate valve


Standard Test

Body Test:1.5 times the working pressure with water. This test is performed after valve assembly and with disc in half position open, it is called as a body hydro test.

Seat Test:1.1 times the working pressure with water.

Function/Operation Test:At the time of final inspection,each valve and its actuator (Flow-Control Lever/ Gear/Pneumatic Actuator),under goes a complete operating test (Open/Close).This test carried out without pressure and at ambient temperature.It ensures the correct operation of the valve/actuator assembly with accessories such as solenoid valve,limit switches,air filter regulator etc.

Special Test:On request,any other test can be carried out according to special instruction by client.



Application

1.Water Treatment Plant          2.Breweries

3.Drilling Rigs                           4. Heating & Air Conditioning

5.Paper Industry                       6.Chemical Industry

7.Gas Plant                               8.Pneumatic Conveyors

9.Sugar Industry                       10.Waste Effluent Treatment Plant

11.Cooling Water Circulation    12.Compressed Air
